2'BSP Thread , 100Liter/Min Suction Strainer
Features
Stainless steel mesh
Re-usable
Epoxy bonded joints for compatibility with all fluids
Rugged steel inner support
Nylon fitting/Nylon end caps (210° max)
100~125 mesh from stock
Options
No by-pass or 3 psi by-pass available
Custom sizes and mesh are available upon request
Model: LESF-KH8(No by-pass )
Norminal Flow:100Liter/Min
Pipe Size: 2'BSP
OD:112mm, 4.41in
Length:225mm,8.86in
Suction Strainer Elements are designed for installation into suction lines of pumps. Extra caution should be taken to ensure that the suction
elements are always mounted below the minimum oil level of the reservoir. Standard models have nominal filtration ratings of 74 or 125 microns.
The suction strainer elements can also be supplied with a bypass valve to reduce high pressure drops caused by contaminated elements or high
viscosity fluids during cold starting. The bypass valve opens at 3 psi. For best results, suction strainer elements should be sized for clean element
pressure drops off no higher than 0.5-.07 psi.
suction Strainer Elements are manufactured using stainless steel wire screen media. Suction strainer elements are only intended to protect hydraulic
pumps against catastrophic failure caused by coarse contaminants. Suction strainer elements should be inspected and cleaned regularly. Suction
strainer elements should not be used as the only filtration elements in a hydraulic system. Pressure filters and return line filters, with reasonable dirt
holding capacity, must be installed to provide protection against component damage caused by fine contaminants.
