Application of the Bag Filter
I. The cement industry
1. The head and tail of the rotary kiln: It generally uses high temperature bag (glass fiber mat, fluorine mae).
2. Shaft kiln: glass fiber filter bags are generally used.
3. Others: Polyester needle-punched felt, waterproof and oil-resistant needle-punched felt and antistatic needle-punched felt are used.
II. Metallurgical industry
(1) Dust removal of the blast furnace gas: Fluorine needle-punched mat is commonly used.
(2) Dust removal of the taphole: Polyester needle-punched felt is generally used.
Steelworks: Polyester needle-punched felt (or mat) or coating needle-punched felt (or mat) is used by electric furnace or converter.
Sintering plants:
(1) Head of the sintering machine: High-temperature glass fiber needle-punched felt is commonly used.
(2) Tail the sintering machine: Polyester needle-punched felt (or mat) or coating needle-punched felt (or mat) is used.
III. Aluminum plants
Polyester needle-punched felt (or mat) is commonly used, but sometimes METAX filter bag is also used.
IV. Power industry
Dust removal of the boiler in the power plant: Imported PPS (polyphenylene sulfide) needle felt is generally used, but some manufacturers also use imported glass fiber coated filter bag or METAX filter bag.
V. Carbon black industry:
Generally used is glass fiber needle felt with PTFE post-processing, but sometimes bulk yarn glass fiber filter bag is also used.
VI. Calcium carbide and ferroalloy industry
Glass fiber filter bag is commonly used, but sometimes fluorine mae filter bag or glass fiber mat filter bag is also used.
Common specifications are as follows, but special size can be customized.
|
133*1000 |
133*1500 |
133*2000 |
133*2450 |
133*3000 |
|
160*1500 |
160*3000 |
160*6000 |
300*2000 |
600*4000 |
