MicroporePolypropylene pleated filter cartridge
is constructed of micro polypropylene media and nonwoven or silk net support . Adaptors are thermally welded with cartridges without using any glue on it, so there will be no any possibilities to cause the second pollution.
Application field:
l Pharmaceutics:antibacterial pharmaceutical lead filter
l Food and beverage:wines 、mineral water 、drinking water filtration
l Oil industry:oilfield water injection filter
l Semiconductor:high pure water lead filter
l Chemical industry :all kinds of acid and alkali organic solvent filter
Products Properties:
Excellent chemical compatibility. Suitable for filtering organic solvents, acid bases.
Pleated design increased the filtration area.
low pressure drop, long service life
Full range of removal ratings
Changing gradual aperture provide super content impurities capacity
FDA authentication material
Technical Specifications
l outer diameter : 69 mm
l Length : 5 '' ,10'' ,20'' ,30'' ,40'' ,50'' ,60'' ,70''
Parts material
l Filter material : polypropylene (PP )
l Support : polypropylene
l Shell /central rod /end cover : polypropylene
l Seal material : silicone rubber ,ethylene propylene rubber ,butadiene acrylonitrile rubber ,fluorine rubber
Filter cartridge
l Filtering precision : 0.1 um .0.22 um ,0.45 um,1 um ,3 um ,5 um ,10 um ,20 um ,50 um
l Maximum operating temperature: 80℃ @1 bar,support adaptors are recommended for temperature exceeds 50℃
● Maximum operating differential pressure: 4.0bar ,normal temperature
● Maximum operating differential pressure (reverse direction): 2.0bar normal temperature
● Sterilization temperature time: 5times, 20 Minute cycles at 120℃
Technical Data
|
Filtering precision |
length |
Plateform |
Seal material |
|
0.1um |
9.75'' |
Double open |
Silicone rubber,
|
|
0.22um |
10'' |
Inside o-rings/ flat blank cap
|
ethylene propylene rubber, |
|
0.45um |
20'' |
222/height222/Triangle pointed/conneres pointed
|
butadiene acrylonitrile rubber, |
|
1um |
30'' |
222/height 222/tail wing |
fluorine rubber |
|
3um |
40'' |
222/height222/flat blank cap |
|
|
5um |
50'' |
226/Triangle pointed/conneres pointed |
|
|
10um |
60'' |
226tail wing |
|
|
20um |
70'' |
226flat blank cap |
|
|
50um |
|
|
|
