KHBF Flange High pressure ball valve
1.The advantages
By controlling the instructions on the handle mandrel slot observe switch position limit switches position through the stopper pin and limit pad, fitted on the control mandrel seal support ring (DN04-50), and equipped with a support ring on the connector body sealing (DN32-50), no leaks, no need to manually re-tune the seals using the principle of the float seal, sealed on both sides, full flow undamped flow easy easy medium through-flow operation.
Surface phosphating, available in stainless steel.
2.Function principle
Rotation control spindle so that the switch the ball from the start position to the closed position, the system pressure of the sphere toward the non-pressure side of the sealed bowl does not leak a cutting stream.
3.Application
Flange High pressure ball valve for the truncated stream hydraulic circuit applications :
1)Pipe connections
2)Marine Equipment
3)Energy supply
4)Power station
4.Hydraulic parameters
1）Working pressure
PN10bar to PN315bar
2）Working medium
Applies to mineral oils, lubricants and other.
3）Working medium temperature
-10 ℃ to +80 ℃
5.Quality assurance
