Primary efficiency cleanable board filter

Primary efficiency cleanable board filter

Read 0 Reviews23 Q&As Write a Review
Primary efficiency cleanable board filter Applications: l Pre-filteringofcentralair-conditioningandcentralventilationssystems l Inletpre-filteringofturbinesandaircompressors. l Householdcentralair-conditioner l Specialusessuchasnuclearandna

PARAMETER

Brand Name:
Model Number:
Nominal filtration rating:
Application:
Operating pressure:
Working temperature:
Replacement or not:Replacement

Primary efficiency cleanable board filter


Applications:



Pre-filtering of central air-conditioning and central ventilations systems

Inlet pre-filtering of turbines and air compressors.

Household central air-conditioner

Special uses such as nuclear and national defense industries.



Features:



Filtering Materials:chemical fiber

Efficiency grade:G3,G4

ABL board filters:aluminum frame,washable,replaceable filtering material

Replaceable filtering media:Customers can change filtering media conveniently.Customers can save cost of spare parts and get rid of the trouble of transportation and storage.



Filtering efficiency:



Filtering efficiencies of ABL has two kinds:G3 and G4.The corresponding efficiency of weight-counting method is 80%-90% and efficiency of colorimetry method is 40% .Filters with these efficiencies as commonly used in the first stage filtering of air-conditioning and ventilation systems,as well as in air-conditioning and ventilation systems that have only one-stage filtering.



The different model is as following:



Model

Class

Size (mm)

Net media(m2)

Rated airflow(m3/h)

Resistance Pa,Via rated airflow

70%      100%       120%

ABL6605-G3

G3

595x595x46

0.6

3600

65

85



ABL3605-G3

G3

290x595x46

0.3

1800

65

85



ABL6610-G3

G3

595x595x96

1.37

3600

30

55

75

ABL3610-G3

G3

290x595x96

0.63

1800

30

55

75

ABL6605-G4

G4

595x595x46

0.6

3600

70

110



ABL3605-G4

G4

290x595x46

0.3

1800

70

110



ABL6610-G4

G4

595x595x96

1.37

3600

45

75

95

ABL3610-G4

G4

290x595x96

0.63

1800

45

75

95



Notes:We can also produce board filters that have the size of G4 and the efficiency of G3.We can produce ABL filters of all sizes according to requirements of customers.But the filters height shall not be than 620mm,and the width not be than 900mm duo to the limited of transportation.
