Pall HNP074 Purifier
Reliability of systems, the service life of system components and fluids are extended by minimising water contamination.
The Pall HNP074 Purifier is designed to remove water from
fluids thereby maintaining lubricity properties, minimising fluid oxidation and reducing aeration.
Benefits of Pall HNP074 Purifier
• High performance water and gas removal
• Simple operation
• Extension of system fluid life
• Increased equipment reliability
• Minimised corrosion within systems
• Reduced fluid disposal
• reduce operating cost
Pall purifiers remove 100% of free water and in excess 80% of dissloved water.They also remove 100% of free and entrained gas and in in excess 80% of dissloved gases.
The Pall HNP074 fluid conditioning purifier can be used as a fixed installation or portable unit that is easily removed and connected to any fluid system.
This purifier design is based on the existing range of Pall fluid conditioning products, it allows for easy operation and control.
Automated controls, integral to the unit constantly monitor the operation of the purifier and will safely shutdown the unit if acceptable limits are exceeded.
Specifications
Dimensions: 680x1997x1580mm (26.8"x78.6"x62.2")
Dry mass: 390kg (860 lbs)
Inlet connections: 2" BSPP or 2" NPT
Outlet connections: 11⁄2" BSPP or 11⁄2" NPT
Flow rate: 70 L/min (18.5 US gpm) at 50 Hz 84 L/min (22.2 US gpm) at 60 Hz
Inlet pressure: 3.0 bar g (300 kPa / 44 psig) maximum
System back pressure: 4.35 bar g (435 kPa / 63.4 psig) maximum
Fluid operating temperature: +10ºC to +70ºC (50°F to 158°F)
Fluid viscosity: 700 cSt (3300 SUS) maximum
Operating vacuum: -0.6 to -0.8 barg [adjustable]
Power supply: 400VAC, 50Hz or 480VAC, 60 Hz
Total Motor power: 6.4kW @ 50Hz / 8.5kW @ 60Hz
