Domnick Hunter air filter element
Product Description
The filter use of absorption-type, pool type to remove oil, water and other impurities from the filtration equipment,be used in filters.
Domnick Hunter Filter use the different structures of the stainless steel frame, corrosion resistance, structural performance, excellent; welding high strength, low resistance to airflow. Different precision levels with different structural type filter, a new "hybrid fiber matrix" to make contact with the medium size area, improved filtration rate, and improve the filtering effect.
Domnick Hnuter Filter used imported material and advanced production process, to ensure the filtering effect and service life.
Technical data:
|
Model of element |
Flow Rate(M3/min) |
||
|
K009 |
0.53 |
||
|
K017 |
1.0 |
||
|
K030 |
1.8 |
||
|
K058 |
3.6 |
||
|
K145 |
8.7 |
||
|
K220 |
13.2 |
||
|
K330 |
19.8 |
||
|
K430 |
25.8 |
||
|
K620 |
37.0 |
||
|
Filtration Accuracy (μm) |
Residual oil component(ppm) |
||
|
PF Class: 25 |
|
||
|
AO Class: 1 |
1 |
||
|
AA Class: 0.01 |
0.01 |
||
|
AX Class: 0.01 |
0.001 |
||
|
ACS Calss: Activated Carbon |
0.001 |
||
|
AR Class: 1 ( Dust remove) |
|
||
|
AAR Class: 0.01 ( Dust Remove) |
|
||
Domnick Hunter part numbers:
|
K009 |
K009AO |
K009AR |
K009AA |
K009AX |
|
K017 |
K017AO |
K017AR |
K017AA |
K017AX |
|
K030 |
K030AO |
K030AR |
K030AA |
K030AX |
|
K058 |
K058AO |
K058AR |
K058AA |
K058AX |
|
K145 |
K145AO |
K145AR |
K145AA |
K145AX |
|
K220 |
K220AO |
K220AR |
K220AA |
K220AX |
|
K330 |
K330AO |
K330AR |
K330AA |
K330AX |
|
K430 |
K430AO |
K430AR |
K430AA |
K430AX |
|
K620 |
K620AO |
K620AR |
K620AA |
K620AX |
Application Fields:
Metallurgy, petrifaction, spinning, electron & pharmacy, power generation & nuclear power, machining equipment, train internal combustion engine & generator, auto engine.
