    HMC type pulse jet single machine dust collector

    Read Reviews23 Q&As Write a Review
    The dust gas of the HMC type pulse jet single machine dust collector enters the ash bucket from the intake port, or enters the filter bag through the open flange mouth. The dust gas is filtered for net gas through the filter bag into the ne

    PARAMETER

    Brand Name: Lefilter
    Model Number: hc9600fkp13h
    Nominal filtration rating:
    Application:Building materials, metallurgy, mining, chemical industry, coal, non-metallic mineral superfine powde
    Operating pressure:
    Working temperature:
    Replacement or not:Replacement

    The dust gas of the HMC type pulse jet single machine dust collector enters the ash bucket from the intake port, or enters the filter bag through the open flange mouth. The dust gas is filtered for net gas through the filter bag into the net gas chamber, and then through the net gas vent, the fan is discharged by the fan. Dust is attached to the outer surface of the filter bag and increases continuously to increase the resistance of the filter bag dust collector. In order to make the resistance of the equipment less than 1200Pa, the bag dust collector can continue to work, and the dust on the filter bag should be cleaned regularly. Ash cleaning is an artery punching valve in the regular sequence of the program controller, which makes the compressed air (0.5-0.7MPa) out of the hole (called one wind) through the venturi tube to induce several times the air around the wind (called the two wind) into the filter bag to make the filter bag expand rapidly and shake off the dust with the reverse effect of the air flow. To the purpose of clearing the ash.
