1. Fan parts adopt universal standard fans, which are convenient for maintenance and replacement, and adopt isolation facilities with little noise.
2, the filter material is chosen as the "729" cylinder filter bag, which has good filtration effect and long service life.
3, the clearing mechanism is the method of using the motor to drive the edge rod mechanism to make the filter bag shake and remove the inner surface of the filter bag. The control device is separated or controlled by the two kinds. The time length of the fire cleaning is adjusted by the time relay (the electronic control box is matched with the dust collector).
4, the ash door adopts two kinds of structure: draw door type and ash door type, so that dust removal is very convenient.
HD single machine dust collector: the dust gas is entered into the box from the inlet of the dust collector and filtered through the filter bag. The dust is left on the inner surface of the filter bag. The gas after the purification enters the fan through the filter bag, and the fan is inhaled directly into the room by the fan, and the exhaust pipe can be discharged to the outside. With the increase of filtration time, the dust adhering to the inner surface of the filter bag is also increasing, and the resistance of the filter bag increases, which requires ash removal.
After the HD single dust collector is cleared, the duster works normally. The machine uses self controlled dust cleaning mechanism to vibrate the dust or hand control cleaning mechanism for dozens of seconds after manual stop, so that the dust on the inner surface of the filter bag will be shaken off. Dust falls into ash hopper, drawers or directly into dust producing equipment.
