movable LYC-A Series Portable oil filter

Read Reviews23 Q&As Write a Review

ProductIntroduction: －Itisusedunderhigh-solidcontentconditions. －especiallyforthefiltrationofoilreclaimerandclarificationfiltrationoffoodoil,.thespecialmaterialswiththickfilterlayersisonetofifteentimesthedepthofothernormalmaterials. －

PARAMETER

Brand Name: Portable oil filter
Model Number: hc9600fkp13h
Nominal filtration rating:3、5、10、20、40
Application:Purifying new oil Filling the new oil and filtrating Purifying oil being used. The bypass filtration in the hydraulic lubrication system .
Operating pressure:0.6
Working temperature: 5-80
Replacement or not:Replacement

Applications
● Purifying new oil
● Filling the new oil and filtrating
● Purifying oil being used.
● The bypass filtration in the hydraulic lubrication system .
Product Performance
1. The oil filter consists of a motor-driven gear pump, dedicating low noise, strong self-absorption capacity, smoothie running characteristics.
2. The high-pressure pipe with overflow protection device, which can effectively protect the safety of hydraulic system.
3. The use of thermal relay protection to prevent motor damage caused by motor overload.
4. The coarse filtration of suction port can protect the pump and extend the life of the main filter.
5. The precision filter chosen by different users for different precision, and can achieve the desired results.
6. Precision oil filtration housing with quick open structure, which can quickly open the cover and replace the filter without any tools.
7. Pressure gauge equipped on the panel, can show the continuous indication of the degree of contamination of the system operating conditions and filter.

型号	LYC-25A-/*	LYC-32A-/*		LYC-40A-/*	LYC-50A-/*	LYC-63A-/*	LYC-100A-/*		LYC-150A-/*
Rated flow L/min	25	32		40	50	63	100		150
Temperature °C	5-80
Recommended viscosity CSt	10-160
Rated pressure MPa	0.6
The original pressure loss MPa	≤0.01
First filtration precision before pump μm	100
Secondary filtration accuracy after pump μm	3、5、10、20、40
Voltage V	Three-phase AC380V Two-phase AC220V
Motor Power kw	0.55		0.75	1.1	1.1	1.5	2.2	3.0
Weight kg	35		64	75	80	85	100	135
Dimensions mm	430X350X950		430X350X950	720X680X1020	720X680X1020	720X680X1020	720X750X1020	720X750X1220
